| Tên thương hiệu: | Fluke |
| Số mẫu: | MS-POE-KIT |
| MOQ: | 1 |
| giá bán: | Negotistical |
The Fluke MS-POE-KIT Industrial Ethernet Cable Tester Kit provides comprehensive PoE network testing capabilities for industrial environments, offering reliable cable verification, Ethernet port detection, and Power over Ethernet testing.
| Parameter | Specification |
|---|---|
| Operating Temperature | 32 °F - 113 °F (0 °C - 45 °C) |
| Storage Temperature | -4 °F - +140 °F (-20 °C - +60 °C) |
| Operating Relative Humidity | 90% (50 °F - 95 °F / 10 °C - 35 °C) 75% (95 °F - 113 °F / 35 °C - 45 °C) |
| Shock and Vibration | Random, 2 g, 5 Hz - 500 Hz (Class 2) |
| Drop Test | 1 m drop test, with or without wiring diagram adapter |
| Safety | IEC 61010-1 Version 3 |
| Altitude | 4000 m; Storage: 12,000 m |
| EMC | IEC 61326-1 |
| Feature | Specification |
|---|---|
| Test Connectors | Shielded 8-pin modular jack, accepts 8-pin modular (RJ45) and 4-pin modular (RJ11) connectors |
| Power Supply | 2 AA (NEDA 15A, IEC LR6) alkaline batteries |
| Battery Life | 20 hours (normal use) |
| Compatible Battery Types | 2 AA camera lithium batteries, NiMH batteries, NiCl3 batteries |
| Dimensions (with batteries) | 3 in x 6.4 in x 1.4 in (7.6 cm x 16.3 cm x 3.6 cm) |
| Weight | 10.6 oz (300 g) |
| Display | Monochrome backlit LCD screen |
Measures length, verifies wiring diagrams, identifies Remote ID locators, and tests Ethernet ports. Displays HIGH Ω when cable resistance exceeds 12.5 Ω. Results displayed on a single screen.
Generates IntelliTone™ and standard analog audio signals for cable tracing and identification.
Requests and detects PoE devices compatible with 802.3af, at, bt, and UPOE (Cisco Universal Power over Ethernet).
| Parameter | Specification |
|---|---|
| Cable Types Tested | Twisted Pair: UTP, FTP, SSTP |
| Length Measurement Range | 460 m (1500 ft) |
| Resolution | 0.3 m (1 ft) |
| Typical Accuracy | ±4% or 0.6 m (2 ft), whichever is greater (plus NVP uncertainty) |
| Calibration | User-configurable twisted-pair NVP value using cable of known length |
| Wiring Diagram Testing | Detects single wire faults, short circuits, misconnections, broken pairs, and up to seven remote adapter IDs |
| Ethernet Port Detection | Detects nominal speeds: 10 Mbps, 100 Mbps, 1 Gbps, 2.5 Gbps, 5 Gbps, and 10 Gbps |
| SmartTone™ Function | Reliably identifies cables in harness using IntelliTone or analog probes |
