Quay cảm biến tốc độ
Created with Pixso.

Zhong He RDZW-2Na Axial Displacement Monitor for Steam Turbine Protection

Zhong He RDZW-2Na Axial Displacement Monitor for Steam Turbine Protection

Tên thương hiệu: Zhong He
Số mẫu: RDZW-2Na
MOQ: 1
giá bán: Có thể đàm phán
Thông tin chi tiết
Nguồn gốc:
Trung Quốc
điện áp cung cấp điện:
DC+24V
cân nặng:
50 gam
Sản lượng hiện tại:
4~20mA
Lớp bảo vệ:
IP64,IP54
tần số đáp ứng:
0,3Hz~1Kz hoặc 1Hz~20KHz
Nhãn hiệu:
Kappapet
Mất watt đầu vào:
dòng điện < 0,2VA, điện áp < 0,1VA
Kích thước chủ đề:
M10×1
Loại cảm biến:
Hiệu ứng phòng
Trở kháng tuyến tính:
250Ω±50Ω (1500Hz)
Vật liệu cánh quạt:
ABS
Phạm vi:
-2,5 đến 2,5 kPa
bộ truyền động thủy lực:
0~200mm
Nhiệt độ xử lý:
-40 đến 125 độ C
Lớp chính xác:
0,5
chi tiết đóng gói:
Hộp gốc mới
Mô tả sản phẩm
Zhong He RDZW-2Na Axial Displacement Monitor for Steam Turbine Protection
Product Overview

The Zhong He RDZW-2Na Axial Displacement Monitor is a professional monitoring and protection instrument dedicated to steam turbines, turbo generators, compressors, fans, and other large rotating machinery. It provides real-time dynamic measurement and safety control of rotor axial displacement, delivering reliable data support for equipment condition monitoring and early fault warning.

Key Features
  • Mature and stable circuit design with high-precision signal conditioning
  • Accurate measurement performance in harsh industrial environments
  • Continuous tracking of rotor axial position changes
  • Automatic comparison with preset alarm and trip values
  • Rapid output of switching signals for over-limit alarm and emergency shutdown protection
  • Clear digital display with intuitive operation interface
  • Flexible parameter configuration capabilities
Technical Capabilities
Supports standard analog signal output and relay alarm output for convenient connection with DCS, PLC, and TSI systems. Features compact structure, high reliability, long service life, and low maintenance cost.
Safety Benefits

Effectively prevents serious accidents including rubbing, blade damage, and shaft bending caused by excessive axial displacement. As a core component of equipment safety protection, the RDZW-2Na helps improve operational stability, reduce unplanned downtime, and extend equipment service life.

Applications

Widely applied in thermal power plants, chemical plants, metallurgical enterprises, and energy equipment industries. Ensures safe, efficient, and continuous operation of steam turbine units.
