ACS1411K61U ABB AC Drive TYPE ACS140 Frequency Converter Frame Size B

ACS1411K61U ABB AC Drive TYPE ACS140 Frequency Converter Frame Size B

Tên thương hiệu: ABB
Số mẫu: ACS141-1K6-1
MOQ: 1
giá bán: Negotiations
Thông tin chi tiết
Nguồn gốc:
Trung Quốc
Loại:
Ổ đĩa
chi tiết đóng gói:
Hộp gốc mới
Làm nổi bật:

ABB ACS140 frequency converter

,

ACS1411K61U AC drive

,

Frame Size B frequency converter

Mô tả sản phẩm
ACS1411K61U ABB AC Drive TYPE ACS140 Frequency Converter Frame Size B
Product Information
Category Drives
Description

ACS1411K61U ABB AC Drive TYPE ACS140 Frequency Converter Frame Size B

  • ACS1411K61
  • AC DRIVE
  • TYPE ACS140 FREQUENCY CONVERTER

ABB Drives ACS 100 AC Frequency Inverter for 0.75kW (1HP) 230V 3 Ph motor in VxF control to 4.3A. Simple to set-up and converts single phase 230V input to three phase 230V for a standard AC Induction motor.

Specifications
Frame Size: B - 80mm Wide x 186mm Deep x 146mm high. IP20 case.
Overload: 150% x 60seconds.
Speed Control Range: 0/300Hz.
Braking: None.
Features: Removable Keypad, 2 x Analogue Inputs, 3 Digital Inputs, 1 Relay Contact set.
EMC Filters: No Internal EMC Filters (External Option).
Input Current: 10.8A.
Input Voltage: 200/240V single phase +-10% at 50/60Hz.
Mounting: Wall mount in clean environment or cubicle mount.
Temperature Rating: Rated at 40C Ambient.
Ventilation Space: Above and below - 25mm. Sides - 0mm.
Heat Loss: At max output - 44W.
Mounting Options: Onto symmetrical DIN rail or use the screw fixings for rear mounting.
