Hệ thống đánh lửa hiệu năng cao
Created with Pixso.

XDH Series XDH-20C High-Energy Ignition Device AC 220V XDZ-1 Ignite Rod Spark Rod Cáp điện áp cao

XDH Series XDH-20C High-Energy Ignition Device AC 220V XDZ-1 Ignite Rod Spark Rod Cáp điện áp cao

Tên thương hiệu: OEM
Số mẫu: XDH-20
MOQ: 1 bộ
Điều khoản thanh toán: T / T
Khả năng cung cấp: 200
Thông tin chi tiết
Nguồn gốc:
Trung Quốc
Vôn:
220V ± 10% 50 / 60HZ
Năng lượng:
20J
Spark thường xuyên:
12-14 lần / S
Kích thước khung:
300 * 200 * 120
que đánh lửa:
M18 * 1.0 M18 * 1.5 M27 * 1.5
Nhiệt độ:
1300 ℃
Thanh dia:
Φ16 Φ18
chi tiết đóng gói:
Đóng gói hộp gỗ
Khả năng cung cấp:
200
Làm nổi bật:

XDH-20C Thiết bị thắp sáng năng lượng cao

,

Thiết bị đốt năng lượng cao AC 220V

,

Mô-đun đốt năng lượng cao

Mô tả sản phẩm

Portable High Performance Ignition System Hea Box for XDH High-Energy Ignition Device Assembly DC 12V, AC 220V



1,Product Description: use from ignition cable input voltage DC discharge in high energy electric spark forming head

2,Technical advantages and honor- Low ignition voltage;- Good temperature resistance;- Safety and reliability, strong ability to resist pollution


Applications:


    As XDH high-energy ignition device assembly.



Specifications:

Brief introduction

1,Product Description: use from ignition cable input voltage DC discharge in high energy electric spark forming head.
2,Technical advantages and honor
- Low ignition voltage;
- Good temperature resistance;
- Safety and reliability,  strong ability to resist pollution

Applications:

As XDH high-energy ignition device assembly.




Product model and series

1. Product series

Sr.

Model

Description

1

XDH-1G

High pressure gap ignitor

2

XDH-2Z

DC charging portable ignition

3

XDH-6B

explosion-proof high-energy ignition

4

XDH-6L

Portable high-energy ignition

5

XDH-12T

Portable high-energy ignition

6

XDH-20B

explosion-proof high-energy ignition

7

XDH-20C

high-energy ignition

8

XDH-20L

high-energy ignition

9

XDH-50

high-energy ignition

【Note】As the series of products still cannot meet the requirements of users,  according to the demand of design.



1. basic configuration:(leave)

2. Performance parameters



Various types of igniter performance:

Parameter name

Unit

Data

NDH-2Z
ignition

NDH-6 series ignition

XDH- 20 series ignition

XDH-50
ignition

Energy storage

J

2

10

20

50

Working voltage

V

DC12

AC220

Output voltage

VDC



2500±5%

Spark frequency

(Times / sec)

1~3

2~10 Adjustable

7~17

2~10  Adjustable

Duty cycle (on / off)

S

30/60

120/60

300/60

120/60



3. Outline and mounting dimensions   pls contact to confirm
